Trim
Cloth - Black £0 ex VAT
Wheels
Full size steel spare wheel £0 ex VAT
Emissions
CO - Not Available
General
Insurance Group 1 - 50 Effective January 07 - Not Available
Emissions
HC+NOx - Not Available
Noise Level dB(A) - Not Available
NOx - Not Available
Particles - Not Available
Standard Euro Emissions - EURO 6
Emissions - ICE
WLTP - CO2 (g/km) - Comb - 220
Engine and Drive Train
Automatic Transmission - No
Cylinders - Bore (mm) - 80
Catalytic Convertor - Yes
CC - 1898
Compression Ratio - 15.9:1
Cooling System - WATER
Cylinder Layout - IN-LINE
Cylinders - 4
Engine Code - RZ4E
Engine Layout - NORTH SOUTH
Engine Make - Not Available
Fuel Delivery - COMMON RAIL
Fuel Delivery - DIESEL
Gears - 6 SPEED
Manual Transmission - Yes
Number of Valves - 16
Cylinders - Stroke (mm) - 94.4
Camshaft - DOHC
Fuel Consumption
EC Directive 1999/100/EC Applies - No
Fuel Consumption - ICE
WLTP - FC (l/100km) - Comb - 8.4
WLTP - FC (l/100km) - Extra High - 9.2
WLTP - FC (l/100km) - High - 7.2
Emissions - PHEV
WLTP - CO2 Charge Depleting (g/km) - Comb - Max - 10.2
Fuel Consumption - ICE
WLTP - FC (l/100km) - Medium - 7.8
WLTP - FC (l/100km) - High - 33.6
WLTP - FC (l/100km) - Low - Min - 30.8
WLTP - FC (l/100km) - Medium - Max - 39.4
WLTP - FC (l/100km) - Extra High - Min - 27.6
WLTP - FC (l/100km) - Comb - Max - 36.4
General
Alternator Amps - 90
Did at least one aspect of this vehicle's safety give cause for concern? - No
Badge Engine CC - 1.9
Badge Power - 164
Based On ID - Not Available
Battery AH - Not Available
Battery Volts - 12
Chassis Engine Number - Not Available
Clutch - SINGLE DRY PLATE
Coin Description - Not Available
Coin Gross Vehicle Weight Code - Not Available
Coin Power Output Code - Not Available
Coin Series - Not Available
Coin Wheelbase Description Code - Not Available
Coin Wheelbase Name Code - Not Available
Exhaust System - CATALYTIC CONVERTER
Front Brakes - VENTILATED DISCS
Front Suspension - TORSION BAR
Timing Belt Interval Mileage - No
Hand Brake - REAR WHEELS
Manufacturers Corrosion Perforation Guarantee - Years - 6
Manufacturers Paintwork Guarantee - Years - 1
Rear Brakes - DRUM
Rear Suspension - LEAF SPRINGS
Running Cost League Headings - MEDIUM
Special Edition - No
Special Order - No
Standard manufacturers warranty - Mileage - 60000
Standard manufacturers warranty - Years - 5
Steering - PAS RACK AND PINION
Service Interval Frequency - Months - No
Vehicle Homologation Class - N1
Vin/Frame No. - Not Available
0 to 62 mph (secs) - 12.7
Engine Power - BHP - 164
Engine Power - KW - 121
Engine Power - RPM - 3600
Engine Torque - LBS.FT - 266
Engine Torque - MKG - 36.7
Engine Torque - NM - 360
Engine Torque - RPM - 2000
Top Speed - 112
Test Cycles
Emissions Test Cycle - WLTP
Tyres
Alloys? - Yes
Automatic Clutch - No
Plated 3rd Axle - Not Available
Plated 4th Axle - Not Available
Space Saver? - No
Tyre Make - Not Available
Tyre Size Front - 265/60 R18
Tyre Size Rear - 265/60 R18
Tyre Size Spare - FULL SIZE
Wheel Style - Not Available
Wheel Type - 18" ALLOY
Vehicle Dimensions
Front Overhang - 890
Height - 1790
Height (including roof rails) - Not Available
Length - 5265
Load Height - Not Available
Load Length - 1805
Load Width - 1530
Lower Rear Door Width - Not Available
Rear Door Height - Not Available
Rear Overhang - 1250
Side Load Door Height - Not Available
Side Load Door Width - Not Available
Upper Rear Door Width - Not Available
Wheelbase - 3125
Width - 1870
Width (including mirrors) - Not Available
Weight and Capacities
Luggage Capacity (Seats Up) - Not Available
Fuel Tank Capacity (Litres) - 76
Gross Train Weight - 6000
Gross Vehicle Weight - 3100
Load Space Volume - Not Available
Luggage Capacity (Seats Down) - Not Available
Luggage Capacity (Seats Down) - Not Available
Luggage Capacity - 2nd Row Seats Removed - Not Available
Luggage Capacity - 2nd Row Seats Up - Not Available
Luggage Capacity - 3rd Row Seats Down - Not Available
Luggage Capacity - 3rd Row Seats Removed - Not Available
Luggage Capacity - 3rd Row Seats Up - Not Available
Max. Roof Load - Not Available
Max. Towing Weight - Braked - 3500
Max. Towing Weight - Unbraked - 750
Minimum Kerbweight - 1952
No. of Seats - 5
Max. Loading Weight - 1148
Plated 2nd Axle - 1910
Plated Front Axle - 1450
General
Generation Mark - 3
Test Cycles
RDE Certification Level - RDE 2
General
NCAP Safety Assist % - 86
NCAP Overall Rating - Effective February 09 - 86
Badge Power - 5
Badge Engine CC - 69
Vehicle Homologation Class - 83
Relative Height - H1
Relative Length - L1
NCAP Overall Rating - LCV - Not Available
Driver Convenience
4.2" Multi function display
4WD shift on the fly
Bluetooth connectivity
Cruise control
Door open warning light
eCall
Forward Collision warning
Lane departure warning and prevention system
Manual gearshift indicator
Multi collision brake
Rear parking sensor
Speed sensitive power steering
Traffic sign recognition
Entertainment
4 speakers
Audio and cruise controls mounted on steering wheel
CD player
Digital radio (DAB)
Front USB connection
Interior Features
6 way adjustable manual driver's seat
Carpet covered floor
Closed upper and open lower glove boxes
Closed upper driver dashboard storage compartment
Cloth upholstery
Driver and passenger sun visors
Driver's footrest
Front centre armrest
Front cup holders in centre console and dash - driver and passenger sides
Front door pockets with bottle holder
Front seat back map pockets
Heated front seats
Height adjustable front headrests
Height and reach adjustable steering wheel
Manual air conditioning
Manual driver's seat lumbar support
Map lights
Rear heater duct
Sunglasses holder and overhead console
Underseat storage compartment
Safety
2x3 point rear seatbelts
Autonomous emergency braking
Front, side, curtain and driver knee SRS airbags
Height adjustable front seatbelt pre-tensioners with load limiters
Passenger airbag deactivation switch
Seatbelt reminder indicator
Security
Alarm with deadlock
Insurance approved immobiliser
Locking wheel nuts
Remote central locking
Technical
12V power outlets
Anti lock braking system (ABS)
Brake assist
EBD
Electronic Stability Control (ESC) with traction control
Hill Descent Control
Hill start assist
Intelligent speed limiter
Rear differential lock
Stop/start function
Wheels
18" silver alloy wheels
Driver Convenience
On/off button for lane support system mounted on steering wheel
One motion door unlock for driver's side
Interior Features
Centre and floor console
Technical
Rear differential lock with harness protector
