On The Road
Registration Fee £55
Twelve Months Road Tax £320
Exterior Features
Metallic paint £575 ex VAT
Solid paint £0 ex VAT
Paintwork
Metallic - Atlantic blue £575 ex VAT
Metallic - Indian red £575 ex VAT
Metallic - Marble grey £575 ex VAT
Metallic - Space black £575 ex VAT
Solid - Grand white £0 ex VAT
Trim
Deluxe cloth - Ash black £0 ex VAT
Emissions
CO - 0.162
General
Insurance Group 1 - 50 Effective January 07 - 0.044
Emissions
HC+NOx - 0.093
Noise Level dB(A) - 75
NOx - 0.05
Particles - 0.0001
Standard Euro Emissions - EURO 6
Emissions - ICE
WLTP - CO2 (g/km) - Comb - 220
WLTP - CO2 (g/km) - Extra High - 238
WLTP - CO2 (g/km) - High - 190
WLTP - CO2 (g/km) - Low - 255
WLTP - CO2 (g/km) - Medium - 207
Engine and Drive Train
Automatic Transmission - No
Cylinders - Bore (mm) - 86.2
Catalytic Convertor - Yes
CC - 2157
Compression Ratio - 15.5:1
Cooling System - WATER
Cylinder Layout - IN-LINE
Cylinders - 4
Engine Code - 672 980
Engine Layout - FRONT TRANSVERSE
Engine Make - SsangYong
Fuel Delivery - COMMON RAIL
Fuel Delivery - DIESEL
Gears - 6 SPEED
Manual Transmission - Yes
Number of Valves - 16
Cylinders - Stroke (mm) - 92.4
Camshaft - DOHC
Fuel Consumption
EC Directive 1999/100/EC Applies - No
Fuel Consumption - ICE
WLTP - FC (l/100km) - Comb - 8.4
WLTP - FC (l/100km) - Extra High - 9.1
WLTP - FC (l/100km) - High - 7.2
Emissions - PHEV
WLTP - CO2 Charge Depleting (g/km) - Comb - Max - 9.7
Fuel Consumption - ICE
WLTP - FC (l/100km) - Medium - 7.9
WLTP - FC (l/100km) - High - 33.8
WLTP - FC (l/100km) - Low - Min - 31.2
WLTP - FC (l/100km) - Medium - Max - 39
WLTP - FC (l/100km) - Extra High - Min - 29.1
WLTP - FC (l/100km) - Comb - Max - 35.8
General
Alternative Fuel Qualifying - No
Did at least one aspect of this vehicle's safety give cause for concern? - No
Badge Engine CC - 2.2
Badge Power - 202
Based On ID - Not Available
Chassis Engine Number - Not Available
Clutch - SINGLE DRY PLATE
Coin Description - Not Available
Coin Gross Vehicle Weight Code - Not Available
Coin Power Output Code - Not Available
Coin Series - Not Available
Coin Wheelbase Description Code - Not Available
Coin Wheelbase Name Code - Not Available
Exhaust System - CATALYTIC CONVERTER
Front Brakes - VENTILATED DISCS
Front Suspension - MCPHERSON STRUT
Generation Mark - 2
Timing Belt Interval Mileage - No
Hand Brake - REAR
Manufacturers Corrosion Perforation Guarantee - Years - 6
Manufacturers Paintwork Guarantee - Years - 3
NCAP Safety Assist % - Not Available
NCAP Overall Rating - Effective February 09 - Not Available
EURO NCAP Front and Side Impact test - Star Rating. - Not Available
Badge Power - Not Available
EURO NCAP Pedestrian test - Star Rating. - Not Available
Badge Engine CC - Not Available
Vehicle Homologation Class - Not Available
Rear Brakes - DISCS
Rear Suspension - COIL SPRING
Running Cost League Headings - Not Available
NCAP Adult Occupant Protection % - 12
Timing Belt Interval Frequency - Months - 12500
Special Edition - No
Special Order - No
Standard manufacturers warranty - Mileage - 100000
Standard manufacturers warranty - Years - 5
Steering - RACK AND PINION
Service Interval Frequency - Months - No
NCAP Pedestrian Protection % - Not Available
NCAP Child Occupant Protection % - Not Available
Vehicle Homologation Class - N1
Vin/Frame No. - Not Available
0 to 62 mph (secs) - Not Available
Engine Power - BHP - 202
Engine Power - KW - 149
Engine Power - RPM - 3800
Engine Torque - LBS.FT - 295
Engine Torque - MKG - 40.8
Engine Torque - NM - 400
Engine Torque - RPM - 1400
Top Speed - 116
Test Cycles
Emissions Test Cycle - WLTP
Tyres
Alloys? - Yes
Plated 3rd Axle - Not Available
Plated 4th Axle - Not Available
Space Saver? - No
Tyre Make - Not Available
Tyre Size Front - 235/70 R17
Tyre Size Rear - 235/70 R17
Tyre Size Spare - TYRE REPAIR KIT
Wheel Style - ALLOY
Wheel Type - 17" ALLOY
Vehicle Dimensions
Front Overhang - 890
Height - 1870
Length - 5095
Rear Overhang - 1105
Weight and Capacities
Turning Circle - Kerb to Kerb - 11.8
Vehicle Dimensions
Wheelbase - 3100
Width - 1950
Width (including mirrors) - 2175
Weight and Capacities
Luggage Capacity (Seats Up) - Not Available
Fuel Tank Capacity (Litres) - 75
Gross Train Weight - 6450
Gross Vehicle Weight - 3250
Luggage Capacity (Seats Down) - Not Available
Luggage Capacity (Seats Down) - Not Available
Luggage Capacity - 2nd Row Seats Removed - Not Available
Luggage Capacity - 2nd Row Seats Up - Not Available
Luggage Capacity - 3rd Row Seats Down - Not Available
Luggage Capacity - 3rd Row Seats Removed - Not Available
Luggage Capacity - 3rd Row Seats Up - Not Available
Max. Roof Load - Not Available
Max. Towing Weight - Braked - 3200
Max. Towing Weight - Unbraked - 750
Minimum Kerbweight - 2145
No. of Seats - 5
Max. Loading Weight - 1105
General
Relative Height - H1
Relative Length - L1
NCAP Overall Rating - LCV - Not Available
Driver Convenience
Automatic headlight control and rain sensing wipers
Bluetooth telephone connectivity
Hydraulic power steering
Instrument cluster with 3.5" monochrome TFT LCD trip computer
TPMS (Tyre pressure monitoring system)
Entertainment
4 speakers
Audio controls mounted on steering wheel
DAB Radio
RDS radio & MP3 player
USB and auxiliary socket
Exterior Features
Body coloured door handles
Chrome ladder style front grille
Daytime running lights
Electric windows
Electric, folding, heated door mirrors with side repeater
Front fog lights
Headlamp levelling
High strength steel construction
Rear wiper
Trailer sway control
Ultra rigid quad frame for greater strength
Visible VIN plate
Windscreen wiper de-icer
Interior Features
A-pillar grab handles
Air vents for rear seat passengers
Automatic de-misting system
Cabin air quality control system
Deluxe cloth upholstery
Glovebox with illumination and key lock
Height adjustable drivers seat
Height adjustable front headrests
Illuminated sun visor with sliding extension
Isofix child seat anchorage points on outer rear seats
Manual air conditioning
PVC Door scuff plates front and rear
Rake adjustable steering wheel
Rear headrests
Rear seat armrest with cupholders
Tyre parking direction indicator
Woven finish accent to fascia, graphite finish to air vents and door tops
Safety
Active roll over protection
Child safety locks
Curtain airbags for front and rear seat passengers
Door impact beams for added protection from side collisions
Dual airbags for driver and front passenger
Front passenger airbag on/off switch
Front seatbelt pretensioners
Seatbelt reminder for all seats
Side airbags for front passengers
Security
Anti theft alarm system
Immobiliser
Remote central locking
Steering column lock
Technical
Anti lock braking system (ABS)
Brake assist
EBD
Electronic stability programme
Hill Descent Control
Hill start assist
Push button start
Traction control
Wheels
17" alloy wheels
Tyre repair kit
